Drainage and plumbing, Grandview-Woodland
Drainage and Plumbing in Grandview-Woodland
Grandview-Woodland calls 3-1-1 about sewer backups more than any other Vancouver neighbourhood, per property. 340 calls across 4,853 civic addresses over four years, which is 70.1 per thousand against a city average of 41.2.
The City has already rebuilt most of the street side here. What has not been rebuilt is the pipe running from the house to it. We camera the line before anybody quotes a number, and the footage is yours.
The City fixed its half. Your half is still 1913
Grandview-Woodland runs from the south shore of Burrard Inlet down to Broadway, with Clark Drive on the west and Nanaimo Street on the east. Strathcona is across Clark, Hastings-Sunrise is across Nanaimo, Kensington-Cedar Cottage is across Broadway, and the water is the north edge. Wall Street, Triumph, Dundas, Oxford, Cambridge, Eton and McGill are all in this neighbourhood, all of them north of Hastings.
We tested every City sewer main segment against the official boundary. 1,686 inside. 860 storm, 655 sanitary, 171 combined. That is 10.1% combined against 24.3% citywide. Clay is 33.7% of the street mains here against 45.5% citywide. On the street side, the City has done most of the work already.
Then look at the houses. 4,986 land parcels carry a build year and 52.3% of them predate 1940. The single biggest decade is the 1910s at 31.3%, close to a third of the neighbourhood in one decade, and a 1910s house is 110 years old now. So the street was rebuilt around you and your lateral was not. That is the whole diagnosis in one line, and it is why the backup number is what it is.
The other thing to know is the grade. Read off 1,510 City manhole cover elevations, the high ground runs down the Victoria Drive side at about 55 to 58 metres and Clark Drive at the bottom sits at 11 to 15 metres. It falls hard to the north too. On Commercial Drive the covers drop from 43.7 metres at 1st Avenue to 5.6 metres near the inlet. Water moves west and north through this neighbourhood, which means if you are on the west slope your uphill neighbours are part of your problem before it ever reaches the street.
Signs worth acting on here
Six calls we take from these streets constantly.
- A backup that happens in August as readily as in November. That is the pipe, not the weather, and the City’s own call pattern here says the same thing.
- Water standing at the curb after heavy rain. There are 1,759 City catch basins inside this neighbourhood. A blocked one, or a missing grate, is a very ordinary cause of a very expensive mess.
- Slow drains on every floor at once. That is the main or the lateral, not the fixture.
- Sewer smell in the basement. On the City’s own table this is a call a plumber problem. It is not on the list they will send a crew for.
- A new suite or duplex, and drains that were fine before it. More fixtures, same old lateral. This is the most common version of the job here.
- Water arriving from uphill. If you sit on the west slope below Victoria Drive, some of what hits your foundation started on somebody else’s lot.
Two different problems that look the same
The City logged 493 street surface water flooding calls and 340 sewer backup calls in Grandview-Woodland over the same four years, and the two behave completely differently.
Street flooding is seasonal. 69% of those calls land in October, November, December and January, with October alone at 110 of the 493. That is rain arriving faster than the surface can move it. The streets that generate the most are Commercial Drive at 38, Powell Street at 25, East Broadway at 24, Victoria Drive at 23, Woodland Drive at 21, and Garden Drive and Grant Street at 19 each.
Sewer backups do not have that shape at all. They run flat through the year, 39 in August against 46 in October. A backup is a pipe problem, not a weather problem, and that distinction changes what we go looking for. Note that the City withholds the addresses on backup calls, so nobody can tell you which house. The flooding addresses are public, and the repeat spots are the 1500 block of Grant Street with 11 calls, Oxford Park at 2050 Wall and 2122 Oxford with 12 between them, the 1900 block of Powell with 10, 705 Woodland Drive with 7, and 1333 East Broadway with 7.
Layer on what has been built since 2017: 1,799 building permits in this neighbourhood, including 259 duplex, 143 single detached house with a secondary suite, 54 multiple conversion dwelling, 38 duplex with secondary suite and 36 laneway house. Every one of those hangs new fixtures off a lateral that was put in a very long time ago.
24/7 emergency dispatch
Backing up in Grandview-Woodland?
Ryan picks up. Live dispatch, and you get a real arrival window on the call. We camera the line before anybody quotes a number, and you keep the footage.
Grandview-Woodland drainage and plumbing FAQ
Because the pipe under the house is much older than the pipe under the street. Only 10.1% of the street mains here are still combined against 24.3% citywide, and clay is 33.7% of them against 45.5% citywide, so the City has already done most of its side. Meanwhile 52.3% of the houses predate 1940 and 31.3% went up in the 1910s alone. Grandview-Woodland leads Vancouver for sewer backup calls per property, 70.1 per thousand addresses against a city average of 41.2.
No, and the City’s own records prove it. 69% of the 493 street flooding calls here land between October and January, with 110 in October alone. The 340 sewer backup calls run flat all year, 39 in August against 46 in October. One is rain arriving faster than the surface can shift it. The other is a pipe that is failing regardless of the weather.
The City lists tree roots and misaligned joints among the most common causes of a sewer backup, and it names holes and cracks caused by damage, age or tree roots as a way extra water gets into a sewer. There are 7,133 City boulevard trees inside Grandview-Woodland and 397 of them measure 80 cm or more through the trunk. East 7th Avenue alone carries 84 red oaks at a median 98 cm. We will not claim a specific tree is in your line. We will camera it and show you.
You are responsible for maintaining the sewer lines on your property, up to where they meet the City’s sewer connection. A licensed plumber is allowed to clean and clear the full portion of the connection from the house to the main, but only the City or its agents may excavate or repair the City’s portion inside the road right of way.
It is. The City says that if you have no sump or clean-out you may have to remove your basement toilet before the crew arrives so they can clear the line, and that City crews will not remove and re-install it. The crew’s job is clearing the blockage and nothing else. It is also worth knowing that only a property owner can request a crew, a tenant cannot, and the City may charge for the call if the problem turns out not to be theirs.
Scope the lateral before you build, not after. Since 2017 the City has issued 143 permits here for a single detached house with a secondary suite, 259 for duplexes, 38 for a duplex with a suite and 36 for laneway houses. Every one of those adds fixtures to a line that in this neighbourhood is very often a hundred years old. Finding out what is down there while the walls are open is far cheaper than finding out afterwards.
Not always, and we would rather say so. The City names three renewal methods, open trenching, pipe bursting and pipe relining, and it describes relining as repairing existing sewer lines temporarily until a more permanent solution can be found. On some lines it is exactly right and it saves your garden. On others it is postponing the real job. The camera decides which, not the price.
Yes. The City’s designated floodplain covers everything from around Cambridge Street down the slope to Wall Street and the inlet, modelled on an extreme storm with a 1 in 500 annual probability plus a metre of sea level rise projected for 2100, and a wave effect zone reaches the far north as well. Oxford Park at 2050 Wall Street and 2122 Oxford Street is on that line and is one of the two most called in flooding spots in the neighbourhood.
A sewer renewal project. The City ran it from 1 April to 30 September 2024 on the local residential streets from East 3rd Avenue to East 8th Avenue, between Lakewood Drive and the lane east of Garden Drive. When the City separates the street, properties on it need separated systems too, and its stated goal is to eliminate sewage overflows by 2050. If you are on those blocks, that is the moment to look at your own connection.
All of Vancouver, plus Burnaby and New Westminster. The three neighbourhoods that actually border this one are Strathcona across Clark Drive, Hastings-Sunrise across Nanaimo Street and Kensington-Cedar Cottage across Broadway, and we are in all three constantly.
